Advanced Tooling for Web Components

This concluding article in our five-part series explores advanced techniques for building Web Components. Previous articles covered creating reusable HTML templates, custom elements, and encapsulating styles with Shadow DOM. We built a custom modal dialog to demonstrate these concepts. Now, we'll examine how to integrate these components into various frameworks and utilize advanced tooling.

Series Summary:

1. Introduction to Web Components
2. Reusable HTML Templates
3. Building Custom Elements
4. Shadow DOM for Style Encapsulation
5. Advanced Web Component Techniques (This article)

Framework Integration

Our modal dialog component is framework-agnostic, functioning seamlessly in most frameworks or even without one (assuming JavaScript is enabled). Angular and Vue readily support Web Components; React requires a slightly different approach.

Angular

Angular, by default, flags unrecognized elements as errors. To use custom elements, include the CUSTOM_ELEMENTS_SCHEMA:

<code>import { NgModule, CUSTOM_ELEMENTS_SCHEMA } from '@angular/core';

@NgModule({
  /** Omitted */
  schemas: [ CUSTOM_ELEMENTS_SCHEMA ]
})
export class MyModuleAllowsCustomElements {}</code>

This allows Angular to accept dash-cased custom elements and properties:

<code><one-dialog>Heading text
  <div>
    <p>Body copy</p>
  </div>
</one-dialog></code>

Vue

Vue's Web Component integration is more straightforward than Angular's, requiring no special configuration. Use standard templating:

<code><one-dialog v-bind:open="isDialogOpen" v-on:dialog-closed="dialogClosed">Heading text
  <div>
    <p>Body copy</p>
  </div>
</one-dialog></code>

Note that integrating custom form controls with Angular's reactive forms or Vue's v-model requires additional setup.

React

React's virtual DOM necessitates a different approach. Direct attribute manipulation isn't used; instead, React's synthetic event system handles events. This means custom events from Web Components require explicit handling.

Using refs provides direct access to the DOM node:

import React, { Component, createRef } from 'react';

export default class MyComponent extends Component {
  // ... (Component code using createRef and event listeners) ...
}

Alternatively, functional components and hooks offer a cleaner solution:

import React, { useState, useEffect, useRef } from 'react';

export default function MyComponent(props) {
  // ... (Functional component code using useRef and useEffect) ...
}

To simplify reuse, a wrapper component can be created:

import React, { Component, createRef } from 'react';
import PropTypes from 'prop-types';

export default class OneDialog extends Component {
  // ... (Wrapper component code) ...
}

This allows native React usage while maintaining a consistent API.

Advanced Tooling

Several tools simplify Web Component development. LitElement, based on lit-html, is a popular choice. It provides APIs for managing properties and rendering, leveraging tagged template literals for dynamic updates:

import { LitElement, html } from 'lit-element';

class SomeComponent extends LitElement {
  // ... (LitElement component code) ...
}

LitElement handles property observation and efficient DOM updates. Other frameworks like Stencil, SkateJS, Angular Elements, and Polymer offer similar capabilities.

Future Directions

Web Component standards continue to evolve. Future enhancements include improved form interaction, native module imports, and advanced template management. These advancements, tracked on the W3C/web components GitHub repository, will further enhance Web Component development.

Web Components are ready for adoption today, with polyfills addressing browser compatibility. They effectively complement existing frameworks, enriching development workflows.
