Beginner Python Project: Build an Augmented Reality Drawing App Using OpenCV and Mediapipe

In this Python project, we'll create a simple AR drawing app. Using your webcam and hand gestures, you can draw virtually on the screen, customize your brush, and even save your creations!

Setup

To get started, create a new folder and initialize a new virtual environment using:

python -m venv venv

./venv/Scripts/activate

Next up install the required libraries using pip or installer of your choice:

pip install mediapipe

pip install opencv-python

Note

You may have trouble installing mediapipe with latest version on python. As I am writing this blog I am using python 3.11.2. Make sure to use the compatible version on python.

Step 1: Capture Webcam Feed

The first step is to set up your webcam and display the video feed. We'll use OpenCV's VideoCapture to access the camera and continuously display frames.

import cv2

# The argument '0' specifies the default camera (usually the built-in webcam).
cap = cv2.VideoCapture(0)

# Start an infinite loop to continuously capture video frames from the webcam
while True:
    # Read a single frame from the webcam
    # `ret` is a boolean indicating success; `frame` is the captured frame.
    ret, frame = cap.read()

    # Check if the frame was successfully captured
    # If not, break the loop and stop the video capture process.
    if not ret:
        break

    # Flip the frame horizontally (like a mirror image)
    frame = cv2.flip(frame, 1)

    # Display the current frame in a window named 'Webcam Feed'
    cv2.imshow('Webcam Feed', frame)

    # Wait for a key press for 1 millisecond
    # If the 'q' key is pressed, break the loop to stop the video feed.
    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

# Release the webcam resource to make it available for other programs
cap.release()

# Close all OpenCV-created windows
cv2.destroyAllWindows()

Did You Know?

When using cv2.waitKey() in OpenCV, the returned key code may include extra bits depending on the platform. To ensure you correctly detect key presses, you can mask the result with 0xFF to isolate the lower 8 bits (the actual ASCII value). Without this, your key comparisons might fail on some systems—so always use & 0xFF for consistent behavior!

Step 2: Integrate Hand Detection

Using Mediapipe's Hands solution, we'll detect the hand and extract the position of key landmarks like the index and middle fingers.

import cv2
import mediapipe as mp

# Initialize the MediaPipe Hands module
mp_hands = mp.solutions.hands  # Load the hand-tracking solution from MediaPipe
hands = mp_hands.Hands(
    min_detection_confidence=0.9,
    min_tracking_confidence=0.9
)

cap = cv2.VideoCapture(0)
while True:
    ret, frame = cap.read()
    if not ret:
        break

    # Flip the frame horizontally to create a mirror effect
    frame = cv2.flip(frame, 1)

    # Convert the frame from BGR (OpenCV default) to RGB (MediaPipe requirement)
    frame_rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)

    # Process the RGB frame to detect and track hands
    result = hands.process(frame_rgb)

    # If hands are detected in the frame
    if result.multi_hand_landmarks:
        # Iterate through all detected hands
        for hand_landmarks in result.multi_hand_landmarks:
            # Get the frame dimensions (height and width)
            h, w, _ = frame.shape

            # Calculate the pixel coordinates of the tip of the index finger
            cx, cy = int(hand_landmarks.landmark[mp_hands.HandLandmark.INDEX_FINGER_TIP].x * w), \
                     int(hand_landmarks.landmark[mp_hands.HandLandmark.INDEX_FINGER_TIP].y * h)

            # Calculate the pixel coordinates of the tip of the middle finger
            mx, my = int(hand_landmarks.landmark[mp_hands.HandLandmark.MIDDLE_FINGER_TIP].x * w), \
                     int(hand_landmarks.landmark[mp_hands.HandLandmark.MIDDLE_FINGER_TIP].y * h)

            # Draw a circle at the index finger tip on the original frame
            cv2.circle(frame, (cx, cy), 10, (0, 255, 0), -1)  # Green circle with radius 10

    # Display the processed frame in a window named 'Webcam Feed'
    cv2.imshow('Webcam Feed', frame)

    if cv2.waitKey(1) & 0xFF == ord('q'):
        break  # Exit the loop if 'q' is pressed

# Release the webcam resources for other programs
cap.release()
cv2.destroyAllWindows()

Step 3: Track Finger Position and Draw

We’ll track the index finger and allow drawing only when the index and middle fingers are separated by a threshold distance.

We'll maintain a list of co-ordinates of the index fingers to draw on the original frame and every time middle finger is close enough, we'll append None to this co-ordinates array indicating a breakage.

import cv2
import mediapipe as mp
import math

# Initialize the MediaPipe Hands module
mp_hands = mp.solutions.hands
hands = mp_hands.Hands(
    min_detection_confidence=0.9,
    min_tracking_confidence=0.9
)

# Variables to store drawing points and reset state
draw_points = []  # A list to store points where lines should be drawn
reset_drawing = False  # Flag to indicate when the drawing should reset

# Brush settings
brush_color = (0, 0, 255)
brush_size = 5


cap = cv2.VideoCapture(0)
while True:
    ret, frame = cap.read()
    if not ret:
        break

    frame = cv2.flip(frame, 1)
    frame_rgb = cv2.cvtColor(frame, cv2.COLOR_BGR2RGB)
    result = hands.process(frame_rgb)

    # If hands are detected
    if result.multi_hand_landmarks:
        for hand_landmarks in result.multi_hand_landmarks:
            h, w, _ = frame.shape  # Get the frame dimensions (height and width)

            # Get the coordinates of the index finger tip
            cx, cy = int(hand_landmarks.landmark[mp_hands.HandLandmark.INDEX_FINGER_TIP].x * w), \
                     int(hand_landmarks.landmark[mp_hands.HandLandmark.INDEX_FINGER_TIP].y * h)

            # Get the coordinates of the middle finger tip
            mx, my = int(hand_landmarks.landmark[mp_hands.HandLandmark.MIDDLE_FINGER_TIP].x * w), \
                     int(hand_landmarks.landmark[mp_hands.HandLandmark.MIDDLE_FINGER_TIP].y * h)

            # Calculate the distance between the index and middle finger tips
            distance = math.sqrt((mx - cx) ** 2 + (my - cy) ** 2)

            # Threshold distance to determine if the fingers are close (used to reset drawing)
            threshold = 40

            # If the fingers are far apart
            if distance > threshold:
                if reset_drawing:  # Check if the drawing was previously reset
                    draw_points.append(None)  # None means no line
                    reset_drawing = False
                draw_points.append((cx, cy))  # Add the current point to the list for drawing
            else:  # If the fingers are close together set the flag to reset drawing
                reset_drawing = True  #

    # Draw the lines between points in the `draw_points` list
    for i in range(1, len(draw_points)):
        if draw_points[i - 1] and draw_points[i]:  # Only draw if both points are valid
            cv2.line(frame, draw_points[i - 1], draw_points[i], brush_color, brush_size)


    cv2.imshow('Webcam Feed', frame)

    if cv2.waitKey(1) & 0xFF == ord('q'):
        break

# Release the webcam and close all OpenCV windows
cap.release()
cv2.destroyAllWindows()

Step 4: Improvements

• Use OpenCV rectangle() and putText() for buttons to toggle brush size and color.
• Add an option to save the frame.
• Add an eraser tool, use the new co-ordinates to modify draw_points array.
