Using EXPLAIN to Write Better MySQL Queries

MySQL Query Optimization with EXPLAIN: A Deep Dive

When you execute a MySQL query, the query optimizer crafts an execution plan. To inspect this plan, use the EXPLAIN command. EXPLAIN is invaluable for understanding and optimizing slow queries, yet many developers underutilize it. This article explores EXPLAIN's output and its application in schema and query optimization.

Key Takeaways:

• Leverage EXPLAIN to analyze query execution plans, pinpoint inefficiencies, and enhance performance.
• Decipher EXPLAIN's output columns (e.g., type, possible_keys, key, rows, Extra) to understand query processing and identify areas for improvement.
• Strategically add indexes to tables based on columns in JOIN or WHERE clauses to drastically reduce row scans, boosting speed and minimizing load times.
• Employ EXPLAIN EXTENDED and SHOW WARNINGS for detailed insights into query transformations and execution, particularly for complex optimization tasks.
• Regularly review and optimize SQL queries using EXPLAIN to maintain optimal database performance, especially in dynamic applications with evolving data.

Understanding EXPLAIN's Output

Simply prefix your SELECT query with EXPLAIN. Let's analyze a basic example:

EXPLAIN SELECT * FROM categoriesG;

A sample output might look like this:

<code>********************** 1. row **********************
           id: 1
  select_type: SIMPLE
        table: categories
         type: ALL
possible_keys: NULL
          key: NULL
      key_len: NULL
          ref: NULL
         rows: 4
        Extra:
1 row in set (0.00 sec)</code>

This seemingly concise output is rich in information. The key columns are:

• id: Sequential identifier for each SELECT in the query (relevant for nested subqueries).
• select_type: Type of SELECT query (SIMPLE, PRIMARY, DERIVED, SUBQUERY, etc.). SIMPLE indicates a straightforward query without subqueries or UNIONs.
• table: Table referenced by the row.
• type: How MySQL joins tables. Crucial for identifying missing indexes or areas for query rewriting. Values range from highly efficient (system, const, eq_ref) to inefficient (ALL, indicating a full table scan).
• possible_keys: Keys potentially usable by MySQL. NULL suggests no relevant indexes.
• key: Actual index used. May differ from possible_keys due to optimizer choices.
• key_len: Length of the chosen index.
• ref: Columns or constants compared to the index in the key column.
• rows: Number of rows examined. A high value points to potential optimization needs, especially with JOINs and subqueries.
• Extra: Additional information (e.g., "Using temporary," "Using filesort"). Consult MySQL documentation for detailed interpretations.

EXPLAIN EXTENDED provides further details. Use SHOW WARNINGS afterward to view query transformations performed by the optimizer:

EXPLAIN SELECT * FROM categoriesG;

Troubleshooting Performance with EXPLAIN

Let's illustrate optimizing a poorly performing query. Consider an e-commerce database (schema available on GitHub) lacking indexes. A poorly written query might look like this:

<code>********************** 1. row **********************
           id: 1
  select_type: SIMPLE
        table: categories
         type: ALL
possible_keys: NULL
          key: NULL
      key_len: NULL
          ref: NULL
         rows: 4
        Extra:
1 row in set (0.00 sec)</code>

The EXPLAIN output will likely reveal "ALL" join types, NULL for possible_keys and key, and extremely high rows values, indicating a full table scan for each table. This is extremely inefficient.

Adding primary keys and indexes (e.g., on columns used in JOIN clauses) dramatically improves performance. Rerunning the EXPLAIN after adding indexes will show significantly lower rows values and more efficient join types ("const," "eq_ref").

Another example involves a UNION of two tables, each joined with productlines:

EXPLAIN EXTENDED SELECT City.Name FROM City JOIN Country ON (City.CountryCode = Country.Code) WHERE City.CountryCode = 'IND' AND Country.Continent = 'Asia';
SHOW WARNINGS;

Without appropriate indexes, EXPLAIN will show full table scans. Adding indexes and strategically placing WHERE conditions within the UNION subqueries can significantly reduce the number of rows scanned.

Summary

EXPLAIN is your ally in MySQL query optimization. By analyzing its output, you can identify and address performance bottlenecks, leading to more efficient and faster queries. Remember that simply adding indexes isn't always sufficient; query structure also plays a vital role. Regular use of EXPLAIN is key to maintaining database health, especially in dynamic applications.
