Building the Earth with WebGL and JavaScript

WebGL offers exciting possibilities for creating immersive 3D experiences directly within web browsers. This tutorial demonstrates building a rotatable 3D Earth model using WebGL and the three.js library.

Key Concepts:

• Leveraging three.js, a WebGL plugin, simplifies 3D model creation.
• The process involves defining a scene, camera, lighting, renderer, and the Earth model itself within a JavaScript file.
• Realistic Earth visuals are achieved using diffuse and bump maps for surface texture and topography.
• Animation is implemented through self-calling functions, subtly rotating the Earth and continuously rendering the scene.

Prerequisites:

This tutorial uses the three.js library. You can include it via a CDN in your HTML:

<🎜>

A div element will serve as the rendering target:

<div id="container"></div>
<🎜>

Setting Up the 3D Environment:

The JavaScript file (earth.js) initializes essential components:

var scene, camera, light, renderer, earthObject;

var WIDTH = window.innerWidth - 30,
    HEIGHT = window.innerHeight - 30;

var angle = 45,
    aspect = WIDTH / HEIGHT,
    near = 0.1,
    far = 3000;

var container = document.getElementById('container');

camera = new THREE.PerspectiveCamera(angle, aspect, near, far);
camera.position.set(0, 0, 0);
scene = new THREE.Scene();

light = new THREE.SpotLight(0xFFFFFF, 1, 0, Math.PI / 2, 1);
light.position.set(4000, 4000, 1500);
light.target.position.set(1000, 3800, 1000);

// ... (Renderer setup and Earth mesh creation will follow)

This code sets up the camera, scene, and lighting. The renderer will be added later.

Creating the Earth Mesh:

A sphere geometry and Phong material are used to create the Earth model:

var earthGeo = new THREE.SphereGeometry(30, 40, 400),
    earthMat = new THREE.MeshPhongMaterial();

var earthMesh = new THREE.Mesh(earthGeo, earthMat);
earthMesh.position.set(-100, 0, 0);
earthMesh.rotation.y = 5;

scene.add(earthMesh);

Adding Textures:

Diffuse and bump maps enhance realism:

// Diffuse map
earthMat.map = THREE.ImageUtils.loadTexture('images/earthmap1k.jpg');

// Bump map
earthMat.bumpMap = THREE.ImageUtils.loadTexture('images/elev_bump_16ka.jpg');
earthMat.bumpScale = 8;

Remember to replace placeholders with actual image paths.

Animating the Earth:

The animate() and render() functions create the rotation effect:

function animate() {
    requestAnimationFrame(animate);
    render();
}

function render() {
    var clock = new THREE.Clock(),
        delta = clock.getDelta();

    earthMesh.rotation.y += rotationSpeed * delta; // rotationSpeed needs to be defined
    renderer.render(scene, camera);
}

animate(); // Start the animation

Complete Example (Illustrative): A full, runnable example would require more code, including renderer setup and potentially additional libraries for controls. The snippets above provide the core elements. Refer to the original article for a complete, functional example.

Further Enhancements:

The tutorial suggests adding features like:

• Orbit controls for interactive rotation.
• A starfield background.
• Atmospheric effects.
